Blind FasteningStructuralMonoboltMonobolt 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
SKU No : SSPV-08-06

Monobolt 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts

Product description :

2.03-9.53 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Dome Head Style with Steel Body material and Steel Mandrel material

Technical Specifications

PropertySpecification
product name
2.032-9.525 mm Steel/Steel Monobolt Structural Blind Rivets
nominal Diameter
6.4mm [1/4] (8)
Body Material
Steel
Mandrel Material
Steel
Finish-Body
Zinc Plate
Finish- Mandrel
Zinc Plate Zinc Trivalent
Head Style
Dome
Min grip mm
2.03
Max grip mm
9.53
Min Grip Inches
0.08
Max Grip Inches
0.375
Min Hole Size mm
6.63
Max Hole Size mm
7.01
Min Holes Size Inches
0.261
Max Hole Size Inches
0.276
Max Body Length mm
14.12
Max Body Length Inches
0.556
Flange Diameter mm
13.46
Flange Diameter inches
0.53
Flange Thickness mm
2.97
Flange Thickness Inches
0.117
Shear lbf
2400
Tensile lbf
1850
Brand
Avdel
