Blind FasteningStructuralQ RivetQ Rivet 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts
SKU No : SSPQ-08-08

Q Rivet 6.4mm [1/4] (8) Steel / Steel Structural Rivet Nuts

Product description :

9.55-12.7 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Dome Head Style with Steel Body material and Steel Mandrel material

Technical Specifications

PropertySpecification
product name
9.5504-12.7 mm Steel/Steel Q Rivet Structural Blind Rivets
nominal Diameter
6.4mm [1/4] (8)
Body Material
Steel
Mandrel Material
Steel
Finish-Body
Zinc Plate
Finish- Mandrel
Zinc Plate
Head Style
Dome
Min grip mm
9.55
Max grip mm
12.7
Min Grip Inches
0.376
Max Grip Inches
0.5
Min Hole Size mm
6.53
Max Hole Size mm
6.63
Min Holes Size Inches
0.257
Max Hole Size Inches
0.261
Max Body Length mm
19.05
Max Body Length Inches
0.75
Max Secondary Protrusion mm
27.05
Max Secondary Protrusion inches
1.065
Flange Diameter mm
13.34
Flange Diameter inches
0.525
Flange Thickness mm
1.96
Flange Thickness Inches
0.077
Shear lbf
1750
Tensile lbf
1450
Brand
Avdel
