SKU No : SSPQ-06-10
Q Rivet 4.8mm [3/16] (6) Steel / Steel Structural Rivet Nuts
Product description :
12.73-15.88 mm grip with 4.8mm [3/16] (6) Nominal Diameter based on Dome Head Style with Steel Body material and Steel Mandrel material
Technical Specifications
| Property | Specification |
|---|---|
product name | 12.7254-15.875 mm Steel/Steel Q Rivet Structural Blind Rivets |
nominal Diameter | 4.8mm [3/16] (6) |
Body Material | Steel |
Mandrel Material | Steel |
Finish-Body | Zinc Plate |
Finish- Mandrel | Zinc Plate |
Head Style | Dome |
Min grip mm | 12.73 |
Max grip mm | 15.88 |
Min Grip Inches | 0.501 |
Max Grip Inches | 0.625 |
Min Hole Size mm | 4.88 |
Max Hole Size mm | 4.98 |
Min Holes Size Inches | 0.192 |
Max Hole Size Inches | 0.196 |
Max Body Length mm | 21.59 |
Max Body Length Inches | 0.85 |
Max Secondary Protrusion mm | 27.99 |
Max Secondary Protrusion inches | 1.102 |
Flange Diameter mm | 10.01 |
Flange Diameter inches | 0.394 |
Flange Thickness mm | 1.45 |
Flange Thickness Inches | 0.057 |
Shear lbf | 1050 |
Tensile lbf | 825 |
Brand | Avdel |
