MONOBOLT®
MONOBOLT® 4.8mm [3/16] (6) Steel / Steel Structural Rivet Nuts
SKU No
:
SSCV-06-06
MONOBOLT® 4.8mm [3/16] (6) Steel / Steel Structural Rivet Nuts
Product description :
3.18-8.41 mm grip with 4.8mm [3/16] (6) Nominal Diameter based on Countersunk Head Style with Steel Body material and Steel Mandrel material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
3.175-8.4074 mm Steel/Steel Monobolt Structural Blind Rivets
product name
Steel
Body Material
Brand
Steel
Mandrel Material
Zinc Plate
Finish-Body
Zinc Plate Zinc Trivalent
Finish- Mandrel
Head Style
Countersunk
Min grip mm
3.18
Max grip mm
8.41
Min Grip Inches
0.125
Max Grip Inches
0.331
Min Hole Size mm
4.93
Max Hole Size mm
5.18
Min Holes Size Inches
0.194
Max Hole Size Inches
0.204
Max Body Length mm
12.34
Max Body Length Inches
0.486
Flange Diameter mm
9.14
Flange Diameter inches
0.36
Flange Thickness mm
1.78
Flange Thickness Inches
0.07
Shear lbf
1300
Tensile lbf
1000
Show more Specifications
