SKU No : SSCQ-05-06
Q Rivet 4.0mm [5/32] (5) Steel / Steel Structural Rivet Nuts
Product description :
6.38-9.53 mm grip with 4.0mm [5/32] (5) Nominal Diameter based on Countersunk Head Style with Steel Body material and Steel Mandrel material
Technical Specifications
| Property | Specification |
|---|---|
product name | 6.3754-9.525 mm Steel/Steel Q Rivet Structural Blind Rivets |
nominal Diameter | 4.0mm [5/32] (5) |
Body Material | Steel |
Mandrel Material | Steel |
Finish-Body | Zinc Plate |
Finish- Mandrel | Zinc Plate |
Head Style | Countersunk |
Min grip mm | 6.38 |
Max grip mm | 9.53 |
Min Grip Inches | 0.251 |
Max Grip Inches | 0.375 |
Min Hole Size mm | 4.06 |
Max Hole Size mm | 4.17 |
Min Holes Size Inches | 0.16 |
Max Hole Size Inches | 0.164 |
Max Body Length mm | 13.97 |
Max Body Length Inches | 0.55 |
Max Secondary Protrusion mm | 19.56 |
Max Secondary Protrusion inches | 0.77 |
Flange Diameter mm | 7.32 |
Flange Diameter inches | 0.288 |
Flange Thickness mm | 1.02 |
Flange Thickness Inches | 0.04 |
Shear lbf | 700 |
Tensile lbf | 550 |
Brand | Avdel |
