Blind FasteningStructuralQ RivetQ Rivet 3.2mm [1/8] (4) Steel / Steel Structural Rivet Nuts
SKU No : SSCQ-04-02

Q Rivet 3.2mm [1/8] (4) Steel / Steel Structural Rivet Nuts

Product description :

1.6-3.18 mm grip with 3.2mm [1/8] (4) Nominal Diameter based on Countersunk Head Style with Steel Body material and Steel Mandrel material

Technical Specifications

PropertySpecification
product name
1.6002-3.175 mm Steel/Steel Q Rivet Structural Blind Rivets
nominal Diameter
3.2mm [1/8] (4)
Body Material
Steel
Mandrel Material
Steel
Finish-Body
Zinc Plate
Finish- Mandrel
Zinc Plate
Head Style
Countersunk
Min grip mm
1.6
Max grip mm
3.18
Min Grip Inches
0.063
Max Grip Inches
0.125
Min Hole Size mm
3.28
Max Hole Size mm
3.38
Min Holes Size Inches
0.129
Max Hole Size Inches
0.133
Max Body Length mm
6.99
Max Body Length Inches
0.275
Max Secondary Protrusion mm
11.73
Max Secondary Protrusion inches
0.462
Flange Diameter mm
5.92
Flange Diameter inches
0.233
Flange Thickness mm
0.81
Flange Thickness Inches
0.032
Shear lbf
500
Tensile lbf
400
Brand
Avdel
