POP 2.4mm [3/32] Steel / Steel Open End Rivets
SKU No
:
SK32BS
POP 2.4mm [3/32] Steel / Steel Open End Rivets
Product description :
0.9144-3.175 mm Grip with 2.4 mm Nominal Diameter in Countersunk Head Style with Steel Body Material and Steel Mandrel Material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
0.9144 - 3.175 Grip in Steel/Steel, Open End Non-Structural Blind Rivets
Product name
2.4
Nominal Diameter mm
Brand
2.4mm [3/32]
Nominal Diameter Inches
Steel
Body Material
Steel
Mandrel Material
Finish-Body
Zinc Plate
Finish- Mandrel
Plain or Protective Coat
Head Style
Countersunk
Min grip mm
0.9144
Max grip mm
3.175
Min Grip Inches
0.036
Max Grip Inches
0.125
Min Hole Size mm
2.4638
Max Hole Size mm
2.54
Min Holes Size Inches
0.097
Max Hole Size Inches
0.1
Max Body Length mm
6.096
Max Body Length Inches
0.24
Max Secondary Protrusion mm
8.635999999999997
Max Secondary Protrusion Inches
0.33999999999999997
Flange Diameter mm Max
4.7498000000000005
Flange Diameter inches Max
0.187
Flange Thickness mm Max
0.9905999999999999
Flange Thickness Inches Max
0.039
Shear kN
0.6672332422890751
Tensile kN
0.91
Shear lbf
150
Tensile lbf
205
Show more Specifications
