SKU No : EB45LH26V1-155

EB45LH26V1-155 EB Series Transducerized Nutrunner

Product description :

EB45LH26V1-155 Lever Start Corded Nutrunner With The Following Features: - Rated For 15.5 - 155 NM With A Recomended Working Range Of 31 - 124 NM - 40-395 RPM - 12 lb Tool Weight - Hold-n-Drive Output - Transducer Controlled With Cm ≥ 3.0, Cmk ≥ 2.67 with +/- 15% single-joint torque scatter capability at 100% rated torque - Direct Drive - Lever Start handle- 1 Inch Retraction

Download 3D Drawings

Download 2D Drawings

Corded
Power Source
Cm ≥ 3.0, Cmk ≥ 2.67 with +/- 15%
External Torque Scatter Rating
Brand
Transducer
Torque Measurement
Direct Drive
Drive Type
Lever Start
Handle Type
Output TypeHold-n-Drive
Recommended Working Range31 - 124 NM
Useful Tool Range15.5 - 155 NM
Max Torque155.0
Min Speed (RPM)40.0
Max Speed (RPM)395.0
