SKU No : 76004-00003

ProSet XT4 - NA version

Product description :

The ProSet® XT4 is the strongest tool of the ProSet family. With 23 kN, the XT4 delivers the highest pull force in the range but weighs in at just about 2 kg. As well as structural breakstem rivets, the high capacity of the XT4 also allows installation of Avdelok®, Maxlok® , and Avtainer® lockbolts. The tool features an ultra-high-tensile piston rod for maximum tool life and a hydraulic damping for smooth operation. The innovative, ergonomic design ensures maximum user comfort and efficiency. The ProSet® XT4 will set 4.0mm (5/32") to 6.4mm (1/4”) diameter rivets in all materials. It will also set 4.8 (3/16") to 6.4mm (1/4”) diameter lockbolts and 6.0 to 12.0mm diameter sealing plugs with additional nose assembly.

Technical Specifications

PropertySpecification
Height
334 mm
Length
330 mm
Weight
2.16 kG
Brand
SAT
Cycle time
1 Seconds
Noise level
75 dB(A)
Vibration
Pull force
23.1 kN
Stroke
20 mm
Minimum aluminium fastener size
6 mm
Minimum steel fastener size
6 mm
Minimum stainless steel fastener size
6 mm
Maximum aluminium fastener size
6.4 mm
Maximum steel fastener size
6.4 mm
Maximum stainless steel fastener size
6.4 mm
