SKU No : 76001-00003

ProSet XT1 - NA version

Product description :

The ProSet® XT3 can be used in a variety of applications, setting a large range of breakstem rivets, lockbolts, and sealing plug sizes. The extremely large stroke of 26 mm allows the placement of longer rivets like Monobolt® and Interlock® in one set. The innovative, ergonomic design ensures maximum user comfort and efficiency. The ProSet® XT3 will set 4.0mm (5/32") to 6.4mm (1/4”) diameter rivets in all materials. It will also set 4.8 (3/16") diameter lockbolts and up to 9.0mm diameter sealing plugs with additional nose assembly.

Technical Specifications

PropertySpecification
Height
245 mm
Length
292 mm
Weight
1.15 kG
Brand
SAT
Cycle time
0.4 Seconds
Noise level
75 dB(A)
Vibration
Pull force
6.5 kN
Stroke
18 mm
Minimum aluminium fastener size
2 mm
Minimum steel fastener size
2 mm
Minimum stainless steel fastener size
2 mm
Maximum aluminium fastener size
4 mm
Maximum steel fastener size
4 mm
Maximum stainless steel fastener size
4 mm
