SKU No : 74202-00005

Prosert XTN20 Imperial - NA version

Product description :

The ProSert XTN20 is a high speed power tool that offers flexible operation in pull-to-stroke and pull-to-force modes. This lightweight but powerful blind rivet nut tool has endurance, excellent ergonomics, and optimal flexibility. Dual operating mode technology ensures enhanced productivity, improving return on investment with the lowest installation cost per fastener. Fast, light, and ergonomic, the ProSert XTN20 increases manufacturing productivity while installing a broad range of thread sizes and grip combinations.

Technical Specifications

PropertySpecification
Height
273 mm
Length
259 mm
Weight
1.59 kG
Brand
SAT
Cycle time
1.5 Seconds
Noise level
75 dB(A)
Vibration
Pull force
17.65 kN
Stroke
7 mm
Minimum aluminium fastener size
M3 mm
Minimum steel fastener size
M3 mm
Minimum stainless steel fastener size
M3 mm
Maximum aluminium fastener size
M10 mm
Maximum steel fastener size
M10 mm
Maximum stainless steel fastener size
M10 mm
