SKU No : 3591-4ENPF500
Heli-Coil 1/4-28 Tanged Screw-Locking Fine Nitronic 60 Wire Thread Inserts 0.5 Inch Primer Free
Product description :
Heli-Coil 1/4-28 Tanged Screw-Locking Fine Nitronic 60 Wire Thread Inserts 0.5 Inch Primer Free
Technical Specifications
| Property | Specification |
|---|---|
Brand | Heli-Coil |
Thread Size | 1/4-28 Inches |
Length | 0.5 Inch |
Locking Feature.1 | Screw-Locking |
Fine/Coarse | Fine |
Finish | Primer Free |
Stripfeed?(Y/N) | N |
Material | Nitronic 60 |
Formed Wire Number | WF-EI-28-C |
Wire Guide | 28.0 |
Wire Guide Ref. | 98688-14 |
Mandrel | 98892-4- |
Mandrel Nut | 98895-4//98896-4-1 |
Machine Type | Model 5A Top Cut-Off |
Cut-off Die | 102011-7 // 3871-57-1 // 3871-57 // 102084 |
Cut-off Punch | 102065 |
Notch | 102062-7 |
Test Bolt | 51369-4 |
Coupon | 51348-4 |
Prewinder | 7552-4 (M) |
