Internally Threaded FastenersWire Thread InsertsTangedHeli-Coil 5/16-24 Tanged Screw-Locking Coarse Stainless Steel Wire Thread Inserts 0.312 Inch Primer Free
SKU No : 3585-5CNPF312

Heli-Coil 5/16-24 Tanged Screw-Locking Coarse Stainless Steel Wire Thread Inserts 0.312 Inch Primer Free

Product description :

Heli-Coil 5/16-24 Tanged Screw-Locking Coarse Stainless Steel Wire Thread Inserts 0.312 Inch Primer Free

Technical Specifications

PropertySpecification
Brand
Heli-Coil
Thread Size
5/16-24 Inches
Length
0.312 Inch
Locking Feature.1
Screw-Locking
Fine/Coarse
Coarse
Finish
Primer Free
Stripfeed?(Y/N)
N
Material
Stainless Steel
Formed Wire Number
WF-CI-24-C
Wire Guide
24.0
Wire Guide Ref.
98688-3
Mandrel
2615-5-
Mandrel Nut
50812-28-10 // 98829-4
Machine Type
Model 5A Top Cut-Off
Cut-off Die
102011-7 // 3871-57-1 // 3871-57 // 102084
Cut-off Punch
102065
Notch
102062-7
Test Bolt
51369-5
Coupon
51348-5
Prewinder
7552-5 (M)
