Internally Threaded FastenersWire Thread InsertsTangedHeli-Coil M24x3 Tanged Free Running Coarse Phosphor Bronze Wire Thread Inserts 36 mm
SKU No : 1084-24BN360

Heli-Coil M24x3 Tanged Free Running Coarse Phosphor Bronze Wire Thread Inserts 36 mm

Product description :

Heli-Coil M24x3 Tanged Free Running Coarse Phosphor Bronze Wire Thread Inserts 36 mm

Technical Specifications

PropertySpecification
Brand
Heli-Coil
Thread Size
M24x3 Metric
Length
36 mm
Locking Feature.1
Free Running
Fine/Coarse
Coarse
Stripfeed?(Y/N)
N
Material
Phosphor Bronze
Formed Wire Number
WF-BI-3-
Wire Guide
3.0
Mandrel
98ll26-24
Mandrel Nut
98827-24
Machine Type
Model 7A
Cut-off Die
102011-6
Cut-off Punch
8
Notch
102062-5 // 102062-3
Test Bolt
51373-24
Coupon
51338-24
Prewinder
7751-24
