Steel / Steel Vgrip Rivets
SKU No
:
101196
Steel / Steel Vgrip Rivets
Product description :
7-10 mm Grip with 4 mm Nominal Diameter in Dome Head Style with Steel Body Material and Steel Mandrel Material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
4.0
Nominal Diameter mm
Steel
Body Material
Brand
Steel
Mandrel Material
Zinc & Clear Passivate + Sealer
Finish-Body
Zinc Plate
Finish- Mandrel
Head Style
Dome
Min grip mm
7
Max grip mm
10
Min Grip Inches
0.276
Max Grip Inches
0.394
Min Hole Size mm
4.1
Max Hole Size mm
4.3
Min Holes Size Inches
0.161
Max Hole Size Inches
0.169
Max Body Length mm
16.3
Max Body Length Inches
0.642
Max Secondary Protrusion mm
18.45
Max Secondary Protrusion Inches
0.726
Flange Diameter mm Max
8.2
Flange Diameter inches Max
0.323
Flange Thickness mm Max
1.4
Shear kN
1.8
Tensile kN
2.8
Nominal Diameter Inches
4.0mm [5/32]
Flange Thickness Inches Max
0.055
Shear lbf
405
Tensile lbf
629
