SKU No : 101090066
R6P 1/8 X 3/8 MS (5/8 LG)
Product description :
R6P 1/8 X 3/8 MS (5/8 LG)
Technical Specifications
| Property | Specification |
|---|---|
Height | 0.125 inches |
Width | 0.375 inches |
Length | 0.625 inches |
Brand | Nelson |
Material (O) | Low Carbon Steel |
Stud Dia | 0.375 inches |
Weld Base Dia | 0.375 inches |
Collar Dia | 0.13 inches |
Overall Length | 0.625 inches |
Head Thickness | 0.218 inches |
Base Length | 0.531 inches |
Extension | 0.749 inches |
Min Base Length | 0.343 inches |
Flash Dia | 0.437 inches |
Flash Thickness | 0.093 inches |
Related Ferrule | 100301002.0 |
Related Chuck | 500005003.0 |
Related Grip | 501001007.0 |
Related Foot | 502001137.0 |
