Blind FasteningStructuralMonoboltMonobolt 6.4mm [1/4] (8) Stainless Steel / Stainless Steel Structural Rivet Nuts
SKU No : 02721-00821

Monobolt 6.4mm [1/4] (8) Stainless Steel / Stainless Steel Structural Rivet Nuts

Product description :

3.17-12.07 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Countersunk Head Style with Stainless Steel Body material and Stainless Steel Mandrel material

Technical Specifications

PropertySpecification
product name
3.17-12.07 mm Stainless Steel/Stainless Steel Monobolt Structural Blind Rivets
nominal Diameter
6.4mm [1/4] (8)
Body Material
Stainless Steel
Mandrel Material
Stainless Steel
Finish-Body
Bright
Finish- Mandrel
Natural
Head Style
Countersunk
Min grip mm
3.17
Max grip mm
12.07
Min Grip Inches
0.1248
Max Grip Inches
306.578
Min Hole Size mm
6.6
Max Hole Size mm
7.0
Min Holes Size Inches
0.2598
Max Hole Size Inches
0.2756
Max Body Length mm
17.27
Max Body Length Inches
0.6799
Max Secondary Protrusion mm
26.34
Max Secondary Protrusion inches
1.037
Flange Diameter mm
0.4
Flange Diameter inches
0.0156
Flange Thickness mm
2.36
Flange Thickness Inches
0.0929
Shear kN
11.787
Tensile kN
10.453
Brand
Avdel
