LockboltsLockbolt FastenersAvtainerAVDEL Steel Lockbolts with 10mm [3/8] nominal diameter with 22.23 - 25.4 mm grip range
SKU No : 02311-01215

AVDEL Steel Lockbolts with 10mm [3/8] nominal diameter with 22.23 - 25.4 mm grip range

Product description :

22.23-25.4 mm grip with 10mm [3/8] Nominal Diameter based on Low Profile Head head style and Steel Pin Material
10mm [3/8]
nominal Diameter
Steel
Pin Material
Brand
Low Profile Head
Head Style
22.23
Min grip mm
25.4
Max grip mm
Min Grip Inches0.875
Max Grip Inches1.0
Min Hole Size mm10.29
Max Hole Size mm10.69
Min Holes Size Inches0.405
Max Hole Size Inches0.421
