Q Rivet 3.2mm [1/8] (4) Stainless Steel / Stainless Steel Structural Rivet Nuts
SKU No
:
CCPQ-04-05
Q Rivet 3.2mm [1/8] (4) Stainless Steel / Stainless Steel Structural Rivet Nuts
Product description :
4.78-7.92 mm grip with 3.2mm [1/8] (4) Nominal Diameter based on Dome Head Style with Stainless Steel Body material and Stainless Steel Mandrel material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
4.7752-7.9248 mm Stainless Steel/Stainless Steel Q Rivet Structural Blind Rivets
product name
3.2mm [1/8] (4)
nominal Diameter
Brand
Stainless Steel
Body Material
Stainless Steel
Mandrel Material
None
Finish-Body
Finish- Mandrel
None
Head Style
Dome
Min grip mm
4.78
Max grip mm
7.92
Min Grip Inches
0.188
Max Grip Inches
0.312
Min Hole Size mm
3.28
Max Hole Size mm
3.38
Min Holes Size Inches
0.129
Max Hole Size Inches
0.133
Max Body Length mm
11.73
Max Body Length Inches
0.462
Max Secondary Protrusion mm
16.48
Max Secondary Protrusion inches
0.649
Flange Diameter mm
6.65
Flange Diameter inches
0.262
Flange Thickness mm
1.07
Flange Thickness Inches
0.042
Shear lbf
700
Tensile lbf
600
