Threaded Shoulder Studs
SBL - Shoulder Stud, Coarse Thread
SBL 1/2 X 2 1/8 MS 3/8-16 EXT
SKU No
:
101093178
SBL 1/2 X 2 1/8 MS 3/8-16 EXT
Product description :
SBL 1/2 X 2 1/8 MS 3/8-16 EXT
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
0.5 inches
Height
0.5 inches
Width
Brand
2.875 inches
Length
0.142 Lb
Weight
Low Carbon Steel
Material (O)
Stud Dia
0.5 inches
Weld Base Dia
0.5 inches
Overall Length
2.875 inches
Weld Base Length
2.125 inches
Burn Off
0.125 inches
Thread Size
3/8-16 UN/UNF
Flash Dia
0.687 inches
Flash Thickness
0.156 inches
Related Ferrule
100101014.0
Related Chuck
500001014.0
Related Grip
501001011.0
Related Foot
502001138.0
