Hemlok 6.4mm [1/4] (8) Aluminum / Aluminum Structural Rivet Nuts
SKU No
:
02241-00821
Hemlok 6.4mm [1/4] (8) Aluminum / Aluminum Structural Rivet Nuts
Product description :
10.8-12.8 mm grip with 6.4mm [1/4] (8) Nominal Diameter based on Dome Head Style with Aluminum Body material and Aluminum Mandrel material
Compare
Add to Smartlist
Talk to an Expert
Tech- Specifications
Features
Download Literature
10.8-12.8 mm Aluminum/Aluminum Hemlok Structural Blind Rivets
product name
6.4mm [1/4] (8)
nominal Diameter
Brand
Aluminium
Body Material
Aluminium
Mandrel Material
Natural
Finish-Body
Finish- Mandrel
Natural
Head Style
Dome
Min grip mm
10.8
Max grip mm
12.8
Min Grip Inches
0.425
Max Grip Inches
0.504
Min Hole Size mm
6.7
Max Hole Size mm
6.9
Min Holes Size Inches
0.264
Max Hole Size Inches
0.272
Max Secondary Protrusion mm
23.0
Max Secondary Protrusion inches
0.9051
Flange Diameter mm
13.4
Flange Diameter inches
0.527
Flange Thickness mm
2.7
Flange Thickness Inches
0.105
Shear kN
7.0
Tensile kN
2.7
Max Body Length mm
23.0
Max Body Length Inches
0.905
Nominal Diameter
6.4mm [1/4]
Max Secondary Protrusion Inches
0.905
Shear lbf
1574.0
Tensile lbf
600.0
Show more Specifications
